Product Description
WyreStorm 4K UHD 4:4:4/60 HDBaseT Extender with HDMI Loop Out and 2-way PoH (70m/230ft) - EX-70-H2X
Manufacturer: WyreStorm
Manufacturer Part Number: EX-70-H2X
Manufacturer Website Address: http://www.wyrestorm.com
Brand Name: WyreStorm
Product Model: EX-70-H2X
Product Name: 4K UHD 4:4:4/60 HDBaseT Extender with HDMI Loop Out and 2-way PoH (70m/230ft)
Marketing Information:
HDMI 2.0 MAXED-OUT
Knowing the speed at which technology moves, at WyreStorm we're always looking ahead. That's why we've included our VLC chipset (Variable Lossless Compression) in this extender meaning seamless support of the next shift in content technology: 4K/60 HDR-10 & HLG and even up to 4:4:4.
HIGH FRAME RATE HDR
HDR Content has recently enjoyed an up-shift in refresh rates after starting its life at 24Hz on UHD Blu-Ray discs. High frame-rate HDR is now available at 60Hz on certain discs and via gaming consoles like the Xbox One X. The EX-70-H2X is now ready to support both HDR-10, HLG at 60Hz and Dolby Vision content up to 30Hz.
FIRST CLASS, CLASS A HDBASET™
Proudly flying the flag for the full Class A HDBaseT™ feature set, the EX-70-H2X levels-up. Supporting not only HDR video, HD Audio and control, but also allowing Ethernet pass-through and 2-way PoH. This allows the extender to be powered from a single PSU, located at either end.
HDMI LOOP OUTPUT
The source loop-output on the transmitter allows a multitude of system expansion options without the need for an external splitter. The signal can be cascaded to a second or third extender to feed extra screens, to a matrix switcher so it can be made part of a larger system or even sent to a NetworkHD encoder forming a hybrid distribution system.
Product Type: Video Extender Transmitter/Receiver
Technical Information
Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 439 ft
Video
Graphics Modes: 4K
Maximum Video Resolution: 4096 x 2160
Interfaces/Ports
Network (RJ-45): Yes
HDMI In: Yes
HDMI Out: Yes
Number of Network (RJ-45) Ports: 2
Number of HDMI Inputs: 1
Number of HDMI Outputs: 2
Media & Performance
Media Type Supported: Twisted Pair
Twisted Pair Cable Standard: Category 7
Physical Characteristics
Transmitter Height: 0.83"
Transmitter Width: 8.27"
Transmitter Depth: 3.73"
Receiver Height: 0.83"
Receiver Width: 8.27"
Receiver Depth: 3.73"
Form Factor:
- Rack-mountable
- Desktop
Transmitter Weight (Approximate): 1.15 lb
Receiver Weight (Approximate): 1.15 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS
