Product Description
HGST Cable Management Arm - 1EX0437
Specifications
Manufacturer: Western Digital Corporation
Manufacturer Part Number: 1EX0437
Manufacturer Website Address: http://www.wdc.com
Brand Name: HGST
Product Name: Cable Management Arm
Marketing Information: The cable management assembly (CMA) provides a number of benefits to protect and manage the cables connected to the PSU ports, SAS ports, and Ethernet ports. It prevents damage to the port connectors and the cables throughout the full travel of the enclosure as it is pulled out of the rack for servicing. This motion ensures that the cables contained by the CMA arm do not snag or get pulled out of the ports as the enclosure moves.
The design of the Ultrastar Data60 CMA is a two-arm design that separates the connections to the two sides of the enclosure. The lower arm supports the cables that connect to the dual SAS ports and Ethernet on the right hand side of the unit as viewed from the rear, as well as the lower PSU power cord. The upper arm supports the left hand ports and the upper PSU power cord. Each arm is attached to the Ultrastar Data60 by one clip at the elbow and two at the other end. The cables are secured to the arms by plastic clips called baskets that can be opened at the top to adjust, add, or remove cables. The arms can also be moved into a service position by unclipping them from the elbow end of the arm and swinging them away from the enclosure when the enclosure is fully inserted in a rack. This provides access to connections and components at the rear of the system without having to remove the CMA or disconnect any of the cabling.
Product Type: Cable Management Arm
Physical Characteristics
Weight (Approximate): 3.40 lb
Miscellaneous
Compatibility:
Manufacturer: Western Digital Corporation
Manufacturer Part Number: 1EX0437
Manufacturer Website Address: http://www.wdc.com
Brand Name: HGST
Product Name: Cable Management Arm
Marketing Information: The cable management assembly (CMA) provides a number of benefits to protect and manage the cables connected to the PSU ports, SAS ports, and Ethernet ports. It prevents damage to the port connectors and the cables throughout the full travel of the enclosure as it is pulled out of the rack for servicing. This motion ensures that the cables contained by the CMA arm do not snag or get pulled out of the ports as the enclosure moves.
The design of the Ultrastar Data60 CMA is a two-arm design that separates the connections to the two sides of the enclosure. The lower arm supports the cables that connect to the dual SAS ports and Ethernet on the right hand side of the unit as viewed from the rear, as well as the lower PSU power cord. The upper arm supports the left hand ports and the upper PSU power cord. Each arm is attached to the Ultrastar Data60 by one clip at the elbow and two at the other end. The cables are secured to the arms by plastic clips called baskets that can be opened at the top to adjust, add, or remove cables. The arms can also be moved into a service position by unclipping them from the elbow end of the arm and swinging them away from the enclosure when the enclosure is fully inserted in a rack. This provides access to connections and components at the rear of the system without having to remove the CMA or disconnect any of the cabling.
Product Type: Cable Management Arm
Physical Characteristics
Weight (Approximate): 3.40 lb
Miscellaneous
Compatibility:
Ultrastar Data60 Hybrid Storage Platform
