Product Description
Tyan B8236G24V4H-IL Barebone System - 1U Rack-mountable - AMD SR5690 Chipset - Socket G34 LGA-1944 - B8236G24V4H-IL
Specifications
Manufacturer: Tyan Computer Corp
Manufacturer Part Number: B8236G24V4H-IL
Manufacturer Website Address: http://www.tyan.com
Brand Name: Tyan
Product Series: GT24
Product Model: B8236G24V4H-IL
Product Name: GT24 B8236G24V4H-IL Barebone System
Marketing Information: Bring your enterprise to the future of server technology! TYAN server solutions offer industry-leading form factors and the features required to build best-in-class server systems to meet your requirements. Aggressively-priced and specifically-engineered for a wide range of applications, TYAN barebones servers and server chassis enclosures provide OEMs, VARs and S/Is with simplified, cost-effective components and solutions for building robust, feature-rich servers.
Product Type: Barebone System
Processor & Chipset
Number of Processors Supported: 2
Processor Socket: Socket G34 LGA-1944
Processor Supported: Opteron
64-bit Processing: Yes
Chipset Manufacturer: AMD
Chipset Model: SR5690
Memory
Maximum Memory: 256 GB
Memory Technology: DDR3 SDRAM
Memory Standard: DDR3-1866/PC3-14900
Number of Total Memory Slots: 16
Controllers
Controller Type: Serial ATA/300
RAID Supported: Yes
Display & Graphics
Graphics Controller Manufacturer: ASPEED
Graphics Controller Model: AST2050
Network & Communication
Ethernet Technology: Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays: 4
Number of Total Expansion Slots: 2
Number of PCI Express x16 Slots: 2
Interfaces/Ports
Total Number of USB Ports: 6
Number of SATA Interfaces: 2
Number of SAS Interfaces: 4
Power Description
Input Voltage:
Maximum Power Supply Wattage: 500 W
Physical Characteristics
Form Factor: Rack-mountable
Rack Height: 1U
Height: 1.7"
Width: 17.2"
Depth: 25.4"
Weight (Approximate): 37.48 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS-6
Manufacturer: Tyan Computer Corp
Manufacturer Part Number: B8236G24V4H-IL
Manufacturer Website Address: http://www.tyan.com
Brand Name: Tyan
Product Series: GT24
Product Model: B8236G24V4H-IL
Product Name: GT24 B8236G24V4H-IL Barebone System
Marketing Information: Bring your enterprise to the future of server technology! TYAN server solutions offer industry-leading form factors and the features required to build best-in-class server systems to meet your requirements. Aggressively-priced and specifically-engineered for a wide range of applications, TYAN barebones servers and server chassis enclosures provide OEMs, VARs and S/Is with simplified, cost-effective components and solutions for building robust, feature-rich servers.
Product Type: Barebone System
Processor & Chipset
Number of Processors Supported: 2
Processor Socket: Socket G34 LGA-1944
Processor Supported: Opteron
64-bit Processing: Yes
Chipset Manufacturer: AMD
Chipset Model: SR5690
Memory
Maximum Memory: 256 GB
Memory Technology: DDR3 SDRAM
Memory Standard: DDR3-1866/PC3-14900
Number of Total Memory Slots: 16
Controllers
Controller Type: Serial ATA/300
RAID Supported: Yes
Display & Graphics
Graphics Controller Manufacturer: ASPEED
Graphics Controller Model: AST2050
Network & Communication
Ethernet Technology: Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays: 4
Number of Total Expansion Slots: 2
Number of PCI Express x16 Slots: 2
Interfaces/Ports
Total Number of USB Ports: 6
Number of SATA Interfaces: 2
Number of SAS Interfaces: 4
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Maximum Power Supply Wattage: 500 W
Physical Characteristics
Form Factor: Rack-mountable
Rack Height: 1U
Height: 1.7"
Width: 17.2"
Depth: 25.4"
Weight (Approximate): 37.48 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS-6
