Product Description
Tripp Lite UPS Smart 5000VA 3750W International Rackmount AVR 230V Pure Sine Wave C13 C19 USB DB9 - SMX5000XLRT3U
Specifications
Manufacturer: Tripp Lite
Manufacturer Part Number: SMX5000XLRT3U
Manufacturer Website Address: http://www.tripplite.com
Brand Name: Tripp Lite
Product Line: SmartPro
Product Name: SMX5000XLRT3U UPS System
Marketing Information: 5000VA line interactive UPS system for server, network and telecommunications equipment. 5kVA UPS with internal batteries installs in only 3 rack spaces with a depth of only 635mm / 25 inches. High 98% line-power efficiency rating reduces energy consumption and BTU heat output. Expandable battery runtime with optional BP48V24-2U (limit 1), BP48V60RT-3U (multi-pack compatible) and BP48V27-2US (multi-pack compatible) external battery packs. Uninterruptible Power Supply (UPS) switches to battery-derived AC output during power failures and extreme voltage variations. Line interactive Automatic Voltage Regulation (AVR) offers voltage boost during brownouts and voltage reduction during overvoltage conditions to maintain regulated 230v output over an input range of 170-282V. Supports hardwire input. Includes C19 and C13 output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support communications via USB, DB9 serial and SNMPWEBCARD slot. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces at once. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. 3-stage metered current monitoring and battery charge status LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rackmount installation accessories included; 2-9USTAND tower kit and 2POSTRMKITHD two post rack mounting accessories available. Field-replaceable, hot-swappable internal batteries and external battery packs.
Product Type: Line-interactive UPS
Technical Information
Plug/Connector Type: Hardwired
Receptacles:
Transfer Time: 4 ms
Power Description
Load Capacity: 5000 VA/3750 W
Input Voltage: 230 V AC
Output Voltage:
Battery Information
Backup/Run Time (Full Load): 8.50 Minute
Typical Battery Recharge Time: 4 Hour
Physical Characteristics
Height: 5.2"
Width: 17.5"
Depth: 25"
Rack Height: 3U
Form Factor: Rack/Tower
Weight (Approximate): 143 lb
Manufacturer: Tripp Lite
Manufacturer Part Number: SMX5000XLRT3U
Manufacturer Website Address: http://www.tripplite.com
Brand Name: Tripp Lite
Product Line: SmartPro
Product Name: SMX5000XLRT3U UPS System
Marketing Information: 5000VA line interactive UPS system for server, network and telecommunications equipment. 5kVA UPS with internal batteries installs in only 3 rack spaces with a depth of only 635mm / 25 inches. High 98% line-power efficiency rating reduces energy consumption and BTU heat output. Expandable battery runtime with optional BP48V24-2U (limit 1), BP48V60RT-3U (multi-pack compatible) and BP48V27-2US (multi-pack compatible) external battery packs. Uninterruptible Power Supply (UPS) switches to battery-derived AC output during power failures and extreme voltage variations. Line interactive Automatic Voltage Regulation (AVR) offers voltage boost during brownouts and voltage reduction during overvoltage conditions to maintain regulated 230v output over an input range of 170-282V. Supports hardwire input. Includes C19 and C13 output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support communications via USB, DB9 serial and SNMPWEBCARD slot. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces at once. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. 3-stage metered current monitoring and battery charge status LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rackmount installation accessories included; 2-9USTAND tower kit and 2POSTRMKITHD two post rack mounting accessories available. Field-replaceable, hot-swappable internal batteries and external battery packs.
Product Type: Line-interactive UPS
Technical Information
Plug/Connector Type: Hardwired
Receptacles:
- 3 x IEC 60320 C19
- 8 x IEC 60320 C13
Transfer Time: 4 ms
Power Description
Load Capacity: 5000 VA/3750 W
Input Voltage: 230 V AC
Output Voltage:
- 220 V AC
- 230 V AC
- 240 V AC
Battery Information
Backup/Run Time (Full Load): 8.50 Minute
Typical Battery Recharge Time: 4 Hour
Physical Characteristics
Height: 5.2"
Width: 17.5"
Depth: 25"
Rack Height: 3U
Form Factor: Rack/Tower
Weight (Approximate): 143 lb
