NEC Display MultiSync EA231WU-BK 22.5" WUXGA WLED LCD Monitor - 16:10 - Black - EA231WU-BK

Specifications
Manufacturer: NEC Display Solutions
Manufacturer Part Number: EA231WU-BK
Manufacturer Website Address: http://www.necdisplay.com
Brand Name: NEC Display
Product Line: MultiSync
Product Series: EA
Product Model: EA231WU-BK
Product Name: MultiSync EA231WU-BK Widescreen LCD Monitor
Marketing Information:

The 23" NEC MultiSync EA231WU is a Wide UXGA (1920x1200) ultra-narrow bezel IPS desktop monitor ideal for corporate environments. Designed for excellent imaging and ideal for multiple monitor configurations, this widescreen model features IPS panel technology with wide viewing angles (178° horizontal/vertical) and ergonomic adjustability. The LED backlighting of the EA231WU allows for a slimmer profile, lighter weight and increased power savings compared to previous generation models.ControlSync™ echnology allows users to control up to six EA231WU displays in a multi-monitor configuration. Upon establishing one unit as the master, users are able to control many performance attributes of the multi-monitor setup in unison through the single monitor. Smart sensing technology automatically detects your work conditions to determine the proper display brightness with ambient light and human sensors. Full-featured connectivity including HDMI, DisplayPort, DVI-D, VGA and 3-port USB 3.1 hub connects users to the latest peripherals and future-proofs your investment.

• LED backlight technology provides for industry-leading low power consumption and less hazardous materials
• Height-adjust, pivot, tilt and swivel capabilities add flexibility and comfort to your viewing preferences
• Full connectivity, including DisplayPort, HDMI, DVI-D and VGA
• Touch-sensitive OSD® controls are integrated into the bezel, making display adjustments easier than ever
• Human and ambient light sensors automatically detect your work conditions to determine the proper display brightness, thereby conserving power
• Certified Low Blue Light and Flicker Free
• ECO Mode™ allows you to manually adjust the display's brightness to your liking, saving power and reducing your energy costs
• dual direction pivot and the image flip feature allow users to arrange the thinnest inactive areas together for nearly seemless images
• NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations
• Compatible with SpectraViewII calibration software and the SVII-EA-KIT calibration kit.

Product Type: LCD Monitor
Technical Information
Number of Screens: 1
Viewable Screen Size: 22.5"
Screen Mode: WUXGA
Response Time: 5 ms
Aspect Ratio: 16:10
Pixel Pitch: 9.8 mil
Backlight Technology: WLED
Horizontal Frequency: 31.50 kHz to 75 kHz - Analog/Digital
Vertical Frequency: 50 Hz to 60 Hz
Video
Maximum Resolution: 1920 x 1200
Color Supported: 16.7 Million Colors
Brightness: 250 Nit - Typical
Color Gamut:

• 69.5% NTSC
• 94.3% sRGB
• 72.9% Adobe RGB

Audio
Speakers: Yes
Interfaces/Ports
DVI: Yes
HDMI: Yes
USB: Yes
VGA: Yes
DisplayPort: Yes
Power Description
Operating Power Consumption: 15 W
Standby Power Consumption: 290 mW
Physical Characteristics
VESA Mount Compatible: Yes
Color: Black
Height: 12.6"
Width: 19.6"
Depth: 1.8"
Height with Stand: 19.20"
Width with Stand: 19.60"
Depth with Stand: 9.80"
Weight (Approximate): 7.50 lb
Weight with Stand (Approximate): 13 lb
Miscellaneous
Energy Star: Yes
Environmentally Friendly: Yes
Environmental Certification:

• TCO Certified Displays 7.0
• ENERGY STAR 7.0
• RoHS
