Product Description
Mellanox 48 Port 10GbE + 12 40/56GbE SDN Switch System - MSX1024B-1BRS
Manufacturer: Mellanox Technologies Ltd
Manufacturer Part Number: MSX1024B-1BRS
Manufacturer Website Address: http://www.mellanox.com
Brand Name: Mellanox
Product Line: SwitchX
Product Model: SX1024
Product Name: 48 Port 10GbE + 12 Port 40/56GbE SDN Switch System
Marketing Information:
With industry leading density, power efficiency and low latency, the SX1024 is the first non-blocking top of rack SDN switch providing unmatched performance advantage while lowering capital and operational expenditures.
The SX1024, is the optimal top of rack switch with 48 port of 10GbE and 12 uplink ports of 40/56GbE for non blocking throughput between rack and aggregation layer. Based on Mellanox's SwitchX®-2 silicon and advanced hardware design this switch packs 48 SFP+ and 12 QSFP interfaces in an ultra dense 1U form factor. the SX1024 features industry leading latency of 250ns and power efficiency while providing optimal performance for enterprise data center, financial services, Web 2.0, high performance computing and cloud computing applications.
Product Type: Ethernet Switch
Interfaces/Ports
Uplink Port: No
Port/Expansion Slot Details:
- 48 x 10 Gigabit Ethernet Expansion Slot
- 12 x Expansion Slot
Media & Performance
Ethernet Technology: 10 Gigabit Ethernet
I/O Expansions
Number of Total Expansion Slots: 60
Expansion Slot Type:
- QSFP
- SFP+
Number of SFP+ Slots: 48
Network & Communication
Layer Supported: 2
Management & Protocols
Manageable: Yes
Power Description
PoE (RJ-45) Port: No
Power Source: Power Supply
Redundant Power Supply Supported: Yes
Physical Characteristics
Compatible Rack Unit: 1U
Form Factor:
- Rack-mountable
- Rail-mountable
Weight (Approximate): 10.98 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS-6
