JBL Professional CWT128 2-way Speaker - White - CWT128-WH

Specifications
Manufacturer: Harman International Industries, Inc
Manufacturer Part Number: CWT128-WH
Manufacturer Website Address: http://www.harman.com
Brand Name: JBL Professional
Product Series: CWT
Product Model: CWT128
Product Name: CWT128 Extremely Wide-Angle Coverage Dual 8" 2-Way Loudspeaker System
Marketing Information:

Dual 8" 2-Way Loudspeaker System featuring CWT Crossfired Waveguide Technology

The JBL Crossfired Waveguide Technology CWT128 is a compact full-range 2-way system designed to provide extremely wide-angle coverage with maximum bandwidth and SPL in a single system package. The unique wide coverage pattern horn is designed to provide seamless coverage to 160-degrees horizontally. CWT128's small footprint makes the system ideal for nearly all architecturally sensitive environments, taking up about a third of the footprint of two speakers splayed side by side.

FEATURES

• Seamless horizontal coverage across a full 160°
• Compact size and small footprint make it ideal for architecturally sensitive environments
• Dual 205 mm (8 in) LF transducers
• Extremely wide-coverage 160° x 60° waveguide
• Dual 25 mm (1") exit, 38 mm (1.5") diaphragm compression driver
• Easy to install with 4 M10 attachment points built in across the top and sides
• 4 M8 points on the back panel accept OmniMount® wall mounting brackets
• WRC and WRX weather resistant versions are available upon request
• CWT128 is available in white - WH

TECHNOLOGY

Crossfired Waveguide Technology (CWT)

At the heart of the CWT128 is the CWT Waveguide featuring a wide coverage pattern designed to provide seamless horizontal coverage across a full 160°. Based on JBL patented technology, the CWT Waveguide is essentially split in half and loaded with two compression drivers facing in different directions.

Proven Dual 2408H-1 Compression Drivers

High frequencies are handled by dual 2408H-1 1" exit, 1.5" diaphragm neodymium compression drivers that deliver higher power levels with lower distortion, better coverage and lighter weight. These proven JBL drivers are renowned for their high power handling and smooth response.

High Performance 8" JBL SFG™ Low Frequency Drivers

Low frequencies are handled by dual 8" JBL SFG™ (Symmetrical Field Geometry) LF drivers each with a copper clad aluminum edge wound 2.5" voice coil and a copper clad pole piece that improves performance by reducing voice coil inductance and distortion. The SFG LF drivers combine smooth response, extended low frequency bandwidth, and extremely low distortion. Delivering an optimum balance of efficiency and bass response, they perfectly complement the CWT Technology.

Product Type: Speaker
Technical Information
Crossover Type: 2-way
Driver Type:

• 8.07" Woofer
• 0.98" Tweeter

Minimum Frequency Response: 71 Hz
Maximum Frequency Response: 20 kHz
Impedance: 8 Ohm
Sensitivity: 129 dB
Physical Characteristics
Color: White
Woofer Diameter: 8.07"
Height: 31.9"
Width: 10.2"
Depth: 11.8"
Weight (Approximate): 41.01 lb
Miscellaneous
Application/Usage:

• Transportation
• Cinema
• Sport Center
• Theme Bar
