Product Description
B+B SmartWorx 5 Port Industrial PoE+ Ethernet Switch with SFP for Fast Fiber - ESWP205-1SFP-T
Specifications
Manufacturer: Advantech Co., Ltd
Manufacturer Part Number: ESWP205-1SFP-T
Manufacturer Website Address: http://www.advantech.com
Brand Name: B+B SmartWorx
Product Model: ESWP205-1SFP-T
Product Name: 5 Port Industrial PoE+ Ethernet Switch with SFP Port for Fast Ethernet Fiber
Marketing Information: The ESWP205-1SFP-T is an Industrial PoE+ Ethernet switch that complies with IEEE 802.3at standards. It provides four PoE+ 10/100Mbps copper ports supplying up to 30W of power to PD devices such as CCTV and WI-FI. An SFP port is available to support 100Mbps fiber SFPs.
Unmanaged and easy to install in a variety of Ethernet applications, it provides PoE+, dual power inputs, wide temperature and an SFP form factor. The ESWP205-1SFP-T is designed to work in hard to reach and harsh environments
Power over Ethernet PoE+ 802.3at provides 30W of power per port and is backwards compatible with 802.3.af devices. The switch detects and classifies a PD device before providing the required power to the PD device. PoE power simplifies the installation of PD devices by eliminating the need for additional cable and power supplies.
Dual Power Input: To reduce the risk of power failure, the ESWP205- 1SFP-T provides two 24 to 52 VDC power inputs. If the power fails, the switch will automatically use the secondary power input.
Flexible Mounting: The switch features a space saving IP30 metal enclosure that can be DIN or Panel mounted.
Small Form-factor Pluggable (SFP) Port: The SFP Port provides flexibility when planning a network. The slot can accept any MSA- compliant SFP module. Available in 100Mbps fiber types for SM, MM and SSF.
Wide Operating Temperature: With an operating temperature of -40 to 85°C (-40 to 185°F), this switch is suitable for use in some of the harshest industrial environments.
Easy Troubleshooting: There are two LED indicators for each copper port that display the link status and transmission speed. There are two LED indicators for power (P1, P2) display power status. There are LED indicators for each copper PoE+ port that show the status of PoE+ power, to indicate if a PD device is connected and functioning.
Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 4
Uplink Port: No
Modular: No
Stack Port: No
Port/Expansion Slot Details:
Media & Performance
Media Type Supported:
Ethernet Technology: Fast Ethernet
Network Technology:
I/O Expansions
Number of Total Expansion Slots: 1
Expansion Slot Type: SFP
Shared SFP Slot: No
Number of SFP Slots: 1
Network & Communication
Layer Supported: 2
Management & Protocols
Manageable: No
Power Description
Power Source: Power Supply
Physical Characteristics
Form Factor:
Height: 4.3"
Width: 1.8"
Depth: 3"
Weight (Approximate): 15.94 oz
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification:
Manufacturer: Advantech Co., Ltd
Manufacturer Part Number: ESWP205-1SFP-T
Manufacturer Website Address: http://www.advantech.com
Brand Name: B+B SmartWorx
Product Model: ESWP205-1SFP-T
Product Name: 5 Port Industrial PoE+ Ethernet Switch with SFP Port for Fast Ethernet Fiber
Marketing Information: The ESWP205-1SFP-T is an Industrial PoE+ Ethernet switch that complies with IEEE 802.3at standards. It provides four PoE+ 10/100Mbps copper ports supplying up to 30W of power to PD devices such as CCTV and WI-FI. An SFP port is available to support 100Mbps fiber SFPs.
Unmanaged and easy to install in a variety of Ethernet applications, it provides PoE+, dual power inputs, wide temperature and an SFP form factor. The ESWP205-1SFP-T is designed to work in hard to reach and harsh environments
Power over Ethernet PoE+ 802.3at provides 30W of power per port and is backwards compatible with 802.3.af devices. The switch detects and classifies a PD device before providing the required power to the PD device. PoE power simplifies the installation of PD devices by eliminating the need for additional cable and power supplies.
Dual Power Input: To reduce the risk of power failure, the ESWP205- 1SFP-T provides two 24 to 52 VDC power inputs. If the power fails, the switch will automatically use the secondary power input.
Flexible Mounting: The switch features a space saving IP30 metal enclosure that can be DIN or Panel mounted.
Small Form-factor Pluggable (SFP) Port: The SFP Port provides flexibility when planning a network. The slot can accept any MSA- compliant SFP module. Available in 100Mbps fiber types for SM, MM and SSF.
Wide Operating Temperature: With an operating temperature of -40 to 85°C (-40 to 185°F), this switch is suitable for use in some of the harshest industrial environments.
Easy Troubleshooting: There are two LED indicators for each copper port that display the link status and transmission speed. There are two LED indicators for power (P1, P2) display power status. There are LED indicators for each copper PoE+ port that show the status of PoE+ power, to indicate if a PD device is connected and functioning.
Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 4
Uplink Port: No
Modular: No
Stack Port: No
Port/Expansion Slot Details:
- 4 x Fast Ethernet Network
- 1 x Fast Ethernet Expansion Slot
Media & Performance
Media Type Supported:
- Optical Fiber
- Twisted Pair
Ethernet Technology: Fast Ethernet
Network Technology:
- 10/100Base-T
- 100Base-X
I/O Expansions
Number of Total Expansion Slots: 1
Expansion Slot Type: SFP
Shared SFP Slot: No
Number of SFP Slots: 1
Network & Communication
Layer Supported: 2
Management & Protocols
Manageable: No
Power Description
Power Source: Power Supply
Physical Characteristics
Form Factor:
- Panel-mountable
- Rail-mountable
Height: 4.3"
Width: 1.8"
Depth: 3"
Weight (Approximate): 15.94 oz
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification:
- RoHS
- WEEE
- REACH
