Aten Seamless Presentation Switch with Quad View Multistreaming - VP2120

Specifications
Manufacturer: ATEN Technology, Inc
Manufacturer Part Number: VP2120
Manufacturer Website Address: http://www.aten-usa.com
Brand Name: Aten
Product Model: VP2120
Product Name: Seamless Presentation Switch with Quad View Multistreaming
Marketing Information:

The ATEN VP2120 Seamless Presentation Switch integrates video matrix switch, AV streaming, audio mixing, and collaborative functions into one compact device.

With one HDMI input, dual HDMI outputs, plus four bi-directional streaming channels, VP2120 empowers BYOD collaboration for more efficient and productive meetings in huddle spaces and huddle rooms, as well as small- to medium-size meeting rooms.

Stream from Any BYOD Device

The VP2120 allows participants to join meetings wirelessly from laptops and smartphones, making collaboration faster and easier than ever before. Just simply log-in and start sharing your presentation content from the Web GUI or from the ATEN Video Presentation Control App on any Apple or Android mobile device.

Simultaneous Bi-directional Multistreaming

Expedite collaboration with bi-directional content streaming among 4 participants simultaneously. Click the "Start Sharing" button to stream-in presentation content from your laptop or mobile device, or "Go Live" to stream-out presentation content in real-time to participants located in different rooms or separate floors.

Quad View Flexibility with Auto Layout

The built-in multi-view mode allows up to 4 streamed-in sources to be displayed in quad view on a single screen, and can dynamically adjust its layout according to the number of sources available. Participants can select a streaming-in source to enlarge and make full-screen, enhancing the flexibility of spontaneous presentation adjustments to meet the needs of fast-moving discussions.

Real-time Whiteboard Annotation

The Whiteboard facilitates discussions by enabling multiple participants to take notes and make annotations on any file in real-time. It provides an intuitive experience by featuring text input, pencil, and image uploads, as well as drag-and-drop and enlarge functions. Whiteboard contents can be saved and shared for efficient post-meeting follow-up.

Instant Chat Room Sharing

The Chat Room enhances interaction and information sharing between participants. Participants can instantly chat with each other or send files to all participants at once to ensure that everyone is on the same page and has access to relevant information for the meeting.

Mobile App for Engaging Collaboration

Join meetings via the ATEN Video Presentation Control App that allows you to share content and collaborate directly from your smartphone. This free app features sharing, Whiteboard, and Chat Room, as well as control capabilities to help you deliver smooth, engaging, and productive meetings.

Data Protection with Secure Connections

VP2120 connects to your existing network infrastructure which ensures the layer of corporate IT security protection needed, especially when it comes to sharing wirelessly. Log-ins can be controlled by randomly generated room codes to ensure that only related people have access to the meeting and the data shared during it.

Product Type: Video Switchbox
Technical Information
Connectivity Technology: Cable
Number of Input Devices Supported: 1
Device Supported:

• Display
• Tablet
• Notebook
• Smartphone

Number of Displays Supported: 2
Video
Maximum Video Resolution: 1920 x 1080
Interfaces/Ports
HDMI In: Yes
HDMI Out: Yes
Connectivity (RJ-45): Yes
Number of Connectivity (RJ-45) Ports: 1
Number of USB Ports: 1
Number of HDMI Inputs: 1
Number of HDMI Outputs: 2
Media & Performance
Media Type Supported: Twisted Pair
Maximum Operating Distance: 49.21 ft
Physical Characteristics
Form Factor: Rack-mountable
Height: 1.7"
Width: 6.7"
Depth: 7.9"
Weight (Approximate): 2.51 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification:

• WEEE
• RoHS
